@ -41,15 +41,18 @@ in C++. |
|
|
|
public: |
|
|
|
Vector2(float x, float y) : x(x), y(y) { } |
|
|
|
|
|
|
|
std::string toString() const { return "[" + std::to_string(x) + ", " + std::to_string(y) + "]"; } |
|
|
|
|
|
|
|
Vector2 operator+(const Vector2 &v) const { return Vector2(x + v.x, y + v.y); } |
|
|
|
Vector2 operator*(float value) const { return Vector2(x * value, y * value); } |
|
|
|
Vector2& operator+=(const Vector2 &v) { x += v.x; y += v.y; return *this; } |
|
|
|
Vector2& operator*=(float v) { x *= v; y *= v; return *this; } |
|
|
|
|
|
|
|
friend Vector2 operator*(float f, const Vector2 &v) { return Vector2(f * v.x, f * v.y); } |
|
|
|
friend Vector2 operator*(float f, const Vector2 &v) { |
|
|
|
return Vector2(f * v.x, f * v.y); |
|
|
|
} |
|
|
|
|
|
|
|
std::string toString() const { |
|
|
|
return "[" + std::to_string(x) + ", " + std::to_string(y) + "]"; |
|
|
|
} |
|
|
|
private: |
|
|
|
float x, y; |
|
|
|
}; |
|
|
|
@ -265,8 +268,14 @@ helper class that is defined as follows: |
|
|
|
|
|
|
|
The macro :func:`PYBIND11_OVERLOAD_PURE` should be used for pure virtual |
|
|
|
functions, and :func:`PYBIND11_OVERLOAD` should be used for functions which have |
|
|
|
a default implementation. The binding code also needs a few minor adaptations |
|
|
|
(highlighted): |
|
|
|
a default implementation. |
|
|
|
|
|
|
|
There are also two alternate macros :func:`PYBIND11_OVERLOAD_PURE_NAME` and |
|
|
|
:func:`PYBIND11_OVERLOAD_NAME` which take a string-valued name argument |
|
|
|
after the *Name of the function* slot. This is useful when the C++ and Python |
|
|
|
versions of the function have different names, e.g. ``operator()`` vs ``__call__``. |
|
|
|
|
|
|
|
The binding code also needs a few minor adaptations (highlighted): |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
:emphasize-lines: 4,6,7 |
|
|
|
@ -310,6 +319,15 @@ a virtual method call. |
|
|
|
>>> call_go(c) |
|
|
|
u'meow! meow! meow! ' |
|
|
|
|
|
|
|
.. warning:: |
|
|
|
|
|
|
|
Both :func:`PYBIND11_OVERLOAD` and :func:`PYBIND11_OVERLOAD_PURE` are |
|
|
|
macros, which means that they can get confused by commas in a template |
|
|
|
argument such as ``PYBIND11_OVERLOAD(MyReturnValue<T1, T2>, myFunc)``. In |
|
|
|
this case, the preprocessor assumes that the comma indicates the beginnning |
|
|
|
of the next parameter. Use a ``typedef`` to bind the template to another |
|
|
|
name and use it in the macro to avoid this problem. |
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/example12.cpp` contains a complete example that |
|
|
|
@ -411,39 +429,52 @@ For this reason, pybind11 provides a several `return value policy` annotations |
|
|
|
that can be passed to the :func:`module::def` and :func:`class_::def` |
|
|
|
functions. The default policy is :enum:`return_value_policy::automatic`. |
|
|
|
|
|
|
|
|
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
| Return value policy | Description | |
|
|
|
+==================================================+===========================================================================+ |
|
|
|
| :enum:`return_value_policy::automatic` | Automatic: copy objects returned as values and take ownership of | |
|
|
|
| | objects returned as pointers | |
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::automatic_reference` | Automatic variant 2 : copy objects returned as values and reference | |
|
|
|
| | objects returned as pointers | |
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::copy` | Create a new copy of the returned object, which will be owned by Python | |
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::take_ownership` | Reference the existing object and take ownership. Python will call | |
|
|
|
| | the destructor and delete operator when the reference count reaches zero | |
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::reference` | Reference the object, but do not take ownership and defer responsibility | |
|
|
|
| | for deleting it to C++ (dangerous when C++ code at some point decides to | |
|
|
|
| | delete it while Python still has a nonzero reference count) | |
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::reference_internal` | Reference the object, but do not take ownership. The object is considered | |
|
|
|
| | be owned by the C++ instance whose method or property returned it. The | |
|
|
|
| | Python object will increase the reference count of this 'parent' by 1 | |
|
|
|
| | to ensure that it won't be deallocated while Python is using the 'child' | |
|
|
|
+--------------------------------------------------+---------------------------------------------------------------------------+ |
|
|
|
|
|
|
|
.. warning:: |
|
|
|
|
|
|
|
Code with invalid call policies might access unitialized memory and free |
|
|
|
data structures multiple times, which can lead to hard-to-debug |
|
|
|
non-determinism and segmentation faults, hence it is worth spending the |
|
|
|
time to understand all the different options above. |
|
|
|
|
|
|
|
See below for an example that uses the |
|
|
|
.. tabularcolumns:: |p{0.5\textwidth}|p{0.45\textwidth}| |
|
|
|
|
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| Return value policy | Description | |
|
|
|
+==================================================+============================================================================+ |
|
|
|
| :enum:`return_value_policy::automatic` | This is the default return value policy, which falls back to the policy | |
|
|
|
| | :enum:`return_value_policy::take_ownership` when the return value is a | |
|
|
|
| | pointer. Otherwise, it uses :enum:`return_value::move` or | |
|
|
|
| | :enum:`return_value::copy` for rvalue and lvalue references, respectively. | |
|
|
|
| | See below for a description of what all of these different policies do. | |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::automatic_reference` | As above, but use policy :enum:`return_value_policy::reference` when the | |
|
|
|
| | return value is a pointer. You probably won't need to use this. | |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::take_ownership` | Reference an existing object (i.e. do not create a new copy) and take | |
|
|
|
| | ownership. Python will call the destructor and delete operator when the | |
|
|
|
| | object's reference count reaches zero. Undefined behavior ensues when the | |
|
|
|
| | C++ side does the same.. | |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::copy` | Create a new copy of the returned object, which will be owned by Python. | |
|
|
|
| | This policy is comparably safe because the lifetimes of the two instances | |
|
|
|
| | are decoupled. | |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::move` | Use ``std::move`` to move the return value contents into a new instance | |
|
|
|
| | that will be owned by Python. This policy is comparably safe because the | |
|
|
|
| | lifetimes of the two instances (move source and destination) are decoupled.| |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::reference` | Reference an existing object, but do not take ownership. The C++ side is | |
|
|
|
| | responsible for managing the object's lifetime and deallocating it when | |
|
|
|
| | it is no longer used. Warning: undefined behavior will ensue when the C++ | |
|
|
|
| | side deletes an object that is still referenced and used by Python. | |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
| :enum:`return_value_policy::reference_internal` | This policy only applies to methods and properties. It references the | |
|
|
|
| | object without taking ownership similar to the above | |
|
|
|
| | :enum:`return_value_policy::reference` policy. In contrast to that policy, | |
|
|
|
| | the function or property's implicit ``this`` argument (called the *parent*)| |
|
|
|
| | is considered to be the the owner of the return value (the *child*). | |
|
|
|
| | pybind11 then couples the lifetime of the parent to the child via a | |
|
|
|
| | reference relationship that ensures that the parent cannot be garbage | |
|
|
|
| | collected while Python is still using the child. More advanced variations | |
|
|
|
| | of this scheme are also possible using combinations of | |
|
|
|
| | :enum:`return_value_policy::reference` and the :class:`keep_alive` call | |
|
|
|
| | policy described next. | |
|
|
|
+--------------------------------------------------+----------------------------------------------------------------------------+ |
|
|
|
|
|
|
|
The following example snippet shows a use case of the |
|
|
|
:enum:`return_value_policy::reference_internal` policy. |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
@ -460,11 +491,36 @@ See below for an example that uses the |
|
|
|
|
|
|
|
py::class_<Example>(m, "Example") |
|
|
|
.def(py::init<>()) |
|
|
|
.def("get_internal", &Example::get_internal, "Return the internal data", py::return_value_policy::reference_internal); |
|
|
|
.def("get_internal", &Example::get_internal, "Return the internal data", |
|
|
|
py::return_value_policy::reference_internal); |
|
|
|
|
|
|
|
return m.ptr(); |
|
|
|
} |
|
|
|
|
|
|
|
.. warning:: |
|
|
|
|
|
|
|
Code with invalid call policies might access unitialized memory or free |
|
|
|
data structures multiple times, which can lead to hard-to-debug |
|
|
|
non-determinism and segmentation faults, hence it is worth spending the |
|
|
|
time to understand all the different options in the table above. |
|
|
|
|
|
|
|
.. note:: |
|
|
|
|
|
|
|
The next section on :ref:`call_policies` discusses *call policies* that can be |
|
|
|
specified *in addition* to a return value policy from the list above. Call |
|
|
|
policies indicate reference relationships that can involve both return values |
|
|
|
and parameters of functions. |
|
|
|
|
|
|
|
.. note:: |
|
|
|
|
|
|
|
As an alternative to elaborate call policies and lifetime management logic, |
|
|
|
consider using smart pointers (see the section on :ref:`smart_pointers` for |
|
|
|
details). Smart pointers can tell whether an object is still referenced from |
|
|
|
C++ or Python, which generally eliminates the kinds of inconsistencies that |
|
|
|
can lead to crashes or undefined behavior. For functions returning smart |
|
|
|
pointers, it is not necessary to specify a return value policy. |
|
|
|
|
|
|
|
.. _call_policies: |
|
|
|
|
|
|
|
Additional call policies |
|
|
|
======================== |
|
|
|
@ -474,12 +530,13 @@ specified to indicate dependencies between parameters. There is currently just |
|
|
|
one policy named ``keep_alive<Nurse, Patient>``, which indicates that the |
|
|
|
argument with index ``Patient`` should be kept alive at least until the |
|
|
|
argument with index ``Nurse`` is freed by the garbage collector; argument |
|
|
|
indices start at one, while zero refers to the return value. Arbitrarily many |
|
|
|
call policies can be specified. |
|
|
|
indices start at one, while zero refers to the return value. For methods, index |
|
|
|
one refers to the implicit ``this`` pointer, while regular arguments begin at |
|
|
|
index two. Arbitrarily many call policies can be specified. |
|
|
|
|
|
|
|
For instance, binding code for a a list append operation that ties the lifetime |
|
|
|
of the newly added element to the underlying container might be declared as |
|
|
|
follows: |
|
|
|
Consider the following example: the binding code for a list append operation |
|
|
|
that ties the lifetime of the newly added element to the underlying container |
|
|
|
might be declared as follows: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
@ -501,7 +558,7 @@ Implicit type conversions |
|
|
|
========================= |
|
|
|
|
|
|
|
Suppose that instances of two types ``A`` and ``B`` are used in a project, and |
|
|
|
that an ``A`` can easily be converted into a an instance of type ``B`` (examples of this |
|
|
|
that an ``A`` can easily be converted into an instance of type ``B`` (examples of this |
|
|
|
could be a fixed and an arbitrary precision number type). |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
@ -557,14 +614,16 @@ The above signature would imply that Python needs to give up ownership of an |
|
|
|
object that is passed to this function, which is generally not possible (for |
|
|
|
instance, the object might be referenced elsewhere). |
|
|
|
|
|
|
|
.. _smart_pointers: |
|
|
|
|
|
|
|
Smart pointers |
|
|
|
============== |
|
|
|
|
|
|
|
This section explains how to pass values that are wrapped in "smart" pointer |
|
|
|
types with internal reference counting. For simpler C++11 unique pointers, |
|
|
|
please refer to the previous section. |
|
|
|
types with internal reference counting. For the simpler C++11 unique pointers, |
|
|
|
refer to the previous section. |
|
|
|
|
|
|
|
The binding generator for classes (:class:`class_`) takes an optional second |
|
|
|
The binding generator for classes, :class:`class_`, takes an optional second |
|
|
|
template type, which denotes a special *holder* type that is used to manage |
|
|
|
references to the object. When wrapping a type named ``Type``, the default |
|
|
|
value of this template parameter is ``std::unique_ptr<Type>``, which means that |
|
|
|
@ -708,6 +767,8 @@ automatically converted into a Python ``Exception``. pybind11 defines multiple |
|
|
|
special exception classes that will map to different types of Python |
|
|
|
exceptions: |
|
|
|
|
|
|
|
.. tabularcolumns:: |p{0.5\textwidth}|p{0.45\textwidth}| |
|
|
|
|
|
|
|
+--------------------------------------+------------------------------+ |
|
|
|
| C++ exception type | Python exception type | |
|
|
|
+======================================+==============================+ |
|
|
|
@ -733,6 +794,10 @@ exceptions: |
|
|
|
| | accesses in ``__getitem__``, | |
|
|
|
| | ``__setitem__``, etc.) | |
|
|
|
+--------------------------------------+------------------------------+ |
|
|
|
| :class:`pybind11::value_error` | ``ValueError`` (used to | |
|
|
|
| | indicate wrong value passed | |
|
|
|
| | in ``container.remove(...)`` | |
|
|
|
+--------------------------------------+------------------------------+ |
|
|
|
| :class:`pybind11::error_already_set` | Indicates that the Python | |
|
|
|
| | exception flag has already | |
|
|
|
| | been initialized | |
|
|
|
@ -746,13 +811,157 @@ There is also a special exception :class:`cast_error` that is thrown by |
|
|
|
:func:`handle::call` when the input arguments cannot be converted to Python |
|
|
|
objects. |
|
|
|
|
|
|
|
.. _opaque: |
|
|
|
|
|
|
|
Treating STL data structures as opaque objects |
|
|
|
============================================== |
|
|
|
|
|
|
|
pybind11 heavily relies on a template matching mechanism to convert parameters |
|
|
|
and return values that are constructed from STL data types such as vectors, |
|
|
|
linked lists, hash tables, etc. This even works in a recursive manner, for |
|
|
|
instance to deal with lists of hash maps of pairs of elementary and custom |
|
|
|
types, etc. |
|
|
|
|
|
|
|
However, a fundamental limitation of this approach is that internal conversions |
|
|
|
between Python and C++ types involve a copy operation that prevents |
|
|
|
pass-by-reference semantics. What does this mean? |
|
|
|
|
|
|
|
Suppose we bind the following function |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
void append_1(std::vector<int> &v) { |
|
|
|
v.push_back(1); |
|
|
|
} |
|
|
|
|
|
|
|
and call it from Python, the following happens: |
|
|
|
|
|
|
|
.. code-block:: python |
|
|
|
|
|
|
|
>>> v = [5, 6] |
|
|
|
>>> append_1(v) |
|
|
|
>>> print(v) |
|
|
|
[5, 6] |
|
|
|
|
|
|
|
As you can see, when passing STL data structures by reference, modifications |
|
|
|
are not propagated back the Python side. A similar situation arises when |
|
|
|
exposing STL data structures using the ``def_readwrite`` or ``def_readonly`` |
|
|
|
functions: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
/* ... definition ... */ |
|
|
|
|
|
|
|
class MyClass { |
|
|
|
std::vector<int> contents; |
|
|
|
}; |
|
|
|
|
|
|
|
/* ... binding code ... */ |
|
|
|
|
|
|
|
py::class_<MyClass>(m, "MyClass") |
|
|
|
.def(py::init<>) |
|
|
|
.def_readwrite("contents", &MyClass::contents); |
|
|
|
|
|
|
|
In this case, properties can be read and written in their entirety. However, an |
|
|
|
``append`` operaton involving such a list type has no effect: |
|
|
|
|
|
|
|
.. code-block:: python |
|
|
|
|
|
|
|
>>> m = MyClass() |
|
|
|
>>> m.contents = [5, 6] |
|
|
|
>>> print(m.contents) |
|
|
|
[5, 6] |
|
|
|
>>> m.contents.append(7) |
|
|
|
>>> print(m.contents) |
|
|
|
[5, 6] |
|
|
|
|
|
|
|
To deal with both of the above situations, pybind11 provides a macro named |
|
|
|
``PYBIND11_MAKE_OPAQUE(T)`` that disables the template-based conversion |
|
|
|
machinery of types, thus rendering them *opaque*. The contents of opaque |
|
|
|
objects are never inspected or extracted, hence they can be passed by |
|
|
|
reference. For instance, to turn ``std::vector<int>`` into an opaque type, add |
|
|
|
the declaration |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
PYBIND11_MAKE_OPAQUE(std::vector<int>); |
|
|
|
|
|
|
|
before any binding code (e.g. invocations to ``class_::def()``, etc.). This |
|
|
|
macro must be specified at the top level, since instantiates a partial template |
|
|
|
overload. If your binding code consists of multiple compilation units, it must |
|
|
|
be present in every file preceding any usage of ``std::vector<int>``. Opaque |
|
|
|
types must also have a corresponding ``class_`` declaration to associate them |
|
|
|
with a name in Python, and to define a set of available operations: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
py::class_<std::vector<int>>(m, "IntVector") |
|
|
|
.def(py::init<>()) |
|
|
|
.def("clear", &std::vector<int>::clear) |
|
|
|
.def("pop_back", &std::vector<int>::pop_back) |
|
|
|
.def("__len__", [](const std::vector<int> &v) { return v.size(); }) |
|
|
|
.def("__iter__", [](std::vector<int> &v) { |
|
|
|
return py::make_iterator(v.begin(), v.end()); |
|
|
|
}, py::keep_alive<0, 1>()) /* Keep vector alive while iterator is used */ |
|
|
|
// .... |
|
|
|
|
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/example14.cpp` contains a complete example that |
|
|
|
demonstrates how to create and expose opaque types using pybind11 in more |
|
|
|
detail. |
|
|
|
|
|
|
|
.. _eigen: |
|
|
|
|
|
|
|
Transparent conversion of dense and sparse Eigen data types |
|
|
|
=========================================================== |
|
|
|
|
|
|
|
Eigen [#f1]_ is C++ header-based library for dense and sparse linear algebra. Due to |
|
|
|
its popularity and widespread adoption, pybind11 provides transparent |
|
|
|
conversion support between Eigen and Scientific Python linear algebra data types. |
|
|
|
|
|
|
|
Specifically, when including the optional header file :file:`pybind11/eigen.h`, |
|
|
|
pybind11 will automatically and transparently convert |
|
|
|
|
|
|
|
1. Static and dynamic Eigen dense vectors and matrices to instances of |
|
|
|
``numpy.ndarray`` (and vice versa). |
|
|
|
|
|
|
|
1. Eigen sparse vectors and matrices to instances of |
|
|
|
``scipy.sparse.csr_matrix``/``scipy.sparse.csc_matrix`` (and vice versa). |
|
|
|
|
|
|
|
This makes it possible to bind most kinds of functions that rely on these types. |
|
|
|
One major caveat are functions that take Eigen matrices *by reference* and modify |
|
|
|
them somehow, in which case the information won't be propagated to the caller. |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
/* The Python bindings of this function won't replicate |
|
|
|
the intended effect of modifying the function argument */ |
|
|
|
void scale_by_2(Eigen::Vector3f &v) { |
|
|
|
v *= 2; |
|
|
|
} |
|
|
|
|
|
|
|
To see why this is, refer to the section on :ref:`opaque` (although that |
|
|
|
section specifically covers STL data types, the underlying issue is the same). |
|
|
|
The next two sections discuss an efficient alternative for exposing the |
|
|
|
underlying native Eigen types as opaque objects in a way that still integrates |
|
|
|
with NumPy and SciPy. |
|
|
|
|
|
|
|
.. [#f1] http://eigen.tuxfamily.org |
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/eigen.cpp` contains a complete example that |
|
|
|
shows how to pass Eigen sparse and dense data types in more detail. |
|
|
|
|
|
|
|
Buffer protocol |
|
|
|
=============== |
|
|
|
|
|
|
|
Python supports an extremely general and convenient approach for exchanging |
|
|
|
data between plugin libraries. Types can expose a buffer view [#f1]_, |
|
|
|
which provides fast direct access to the raw internal representation. Suppose |
|
|
|
we want to bind the following simplistic Matrix class: |
|
|
|
data between plugin libraries. Types can expose a buffer view [#f2]_, which |
|
|
|
provides fast direct access to the raw internal data representation. Suppose we |
|
|
|
want to bind the following simplistic Matrix class: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
@ -770,7 +979,7 @@ we want to bind the following simplistic Matrix class: |
|
|
|
}; |
|
|
|
|
|
|
|
The following binding code exposes the ``Matrix`` contents as a buffer object, |
|
|
|
making it possible to cast Matrixes into NumPy arrays. It is even possible to |
|
|
|
making it possible to cast Matrices into NumPy arrays. It is even possible to |
|
|
|
completely avoid copy operations with Python expressions like |
|
|
|
``np.array(matrix_instance, copy = False)``. |
|
|
|
|
|
|
|
@ -779,12 +988,12 @@ completely avoid copy operations with Python expressions like |
|
|
|
py::class_<Matrix>(m, "Matrix") |
|
|
|
.def_buffer([](Matrix &m) -> py::buffer_info { |
|
|
|
return py::buffer_info( |
|
|
|
m.data(), /* Pointer to buffer */ |
|
|
|
sizeof(float), /* Size of one scalar */ |
|
|
|
py::format_descriptor<float>::value(), /* Python struct-style format descriptor */ |
|
|
|
2, /* Number of dimensions */ |
|
|
|
{ m.rows(), m.cols() }, /* Buffer dimensions */ |
|
|
|
{ sizeof(float) * m.rows(), /* Strides (in bytes) for each index */ |
|
|
|
m.data(), /* Pointer to buffer */ |
|
|
|
sizeof(float), /* Size of one scalar */ |
|
|
|
py::format_descriptor<float>::value, /* Python struct-style format descriptor */ |
|
|
|
2, /* Number of dimensions */ |
|
|
|
{ m.rows(), m.cols() }, /* Buffer dimensions */ |
|
|
|
{ sizeof(float) * m.rows(), /* Strides (in bytes) for each index */ |
|
|
|
sizeof(float) } |
|
|
|
); |
|
|
|
}); |
|
|
|
@ -810,41 +1019,71 @@ in a great variety of configurations, hence some safety checks are usually |
|
|
|
necessary in the function body. Below, you can see an basic example on how to |
|
|
|
define a custom constructor for the Eigen double precision matrix |
|
|
|
(``Eigen::MatrixXd``) type, which supports initialization from compatible |
|
|
|
buffer |
|
|
|
objects (e.g. a NumPy matrix). |
|
|
|
buffer objects (e.g. a NumPy matrix). |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
py::class_<Eigen::MatrixXd>(m, "MatrixXd") |
|
|
|
.def("__init__", [](Eigen::MatrixXd &m, py::buffer b) { |
|
|
|
/* Bind MatrixXd (or some other Eigen type) to Python */ |
|
|
|
typedef Eigen::MatrixXd Matrix; |
|
|
|
|
|
|
|
typedef Matrix::Scalar Scalar; |
|
|
|
constexpr bool rowMajor = Matrix::Flags & Eigen::RowMajorBit; |
|
|
|
|
|
|
|
py::class_<Matrix>(m, "Matrix") |
|
|
|
.def("__init__", [](Matrix &m, py::buffer b) { |
|
|
|
typedef Eigen::Stride<Eigen::Dynamic, Eigen::Dynamic> Strides; |
|
|
|
|
|
|
|
/* Request a buffer descriptor from Python */ |
|
|
|
py::buffer_info info = b.request(); |
|
|
|
|
|
|
|
/* Some sanity checks ... */ |
|
|
|
if (info.format != py::format_descriptor<double>::value()) |
|
|
|
if (info.format != py::format_descriptor<Scalar>::value) |
|
|
|
throw std::runtime_error("Incompatible format: expected a double array!"); |
|
|
|
|
|
|
|
if (info.ndim != 2) |
|
|
|
throw std::runtime_error("Incompatible buffer dimension!"); |
|
|
|
|
|
|
|
if (info.strides[0] == sizeof(double)) { |
|
|
|
/* Buffer has the right layout -- directly copy. */ |
|
|
|
new (&m) Eigen::MatrixXd(info.shape[0], info.shape[1]); |
|
|
|
memcpy(m.data(), info.ptr, sizeof(double) * m.size()); |
|
|
|
} else { |
|
|
|
/* Oops -- the buffer is transposed */ |
|
|
|
new (&m) Eigen::MatrixXd(info.shape[1], info.shape[0]); |
|
|
|
memcpy(m.data(), info.ptr, sizeof(double) * m.size()); |
|
|
|
m.transposeInPlace(); |
|
|
|
} |
|
|
|
auto strides = Strides( |
|
|
|
info.strides[rowMajor ? 0 : 1] / sizeof(Scalar), |
|
|
|
info.strides[rowMajor ? 1 : 0] / sizeof(Scalar)); |
|
|
|
|
|
|
|
auto map = Eigen::Map<Matrix, 0, Strides>( |
|
|
|
static_cat<Scalar *>(info.ptr), info.shape[0], info.shape[1], strides); |
|
|
|
|
|
|
|
new (&m) Matrix(map); |
|
|
|
}); |
|
|
|
|
|
|
|
For reference, the ``def_buffer()`` call for this Eigen data type should look |
|
|
|
as follows: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
.def_buffer([](Matrix &m) -> py::buffer_info { |
|
|
|
return py::buffer_info( |
|
|
|
m.data(), /* Pointer to buffer */ |
|
|
|
sizeof(Scalar), /* Size of one scalar */ |
|
|
|
/* Python struct-style format descriptor */ |
|
|
|
py::format_descriptor<Scalar>::value, |
|
|
|
/* Number of dimensions */ |
|
|
|
2, |
|
|
|
/* Buffer dimensions */ |
|
|
|
{ (size_t) m.rows(), |
|
|
|
(size_t) m.cols() }, |
|
|
|
/* Strides (in bytes) for each index */ |
|
|
|
{ sizeof(Scalar) * (rowMajor ? m.cols() : 1), |
|
|
|
sizeof(Scalar) * (rowMajor ? 1 : m.rows()) } |
|
|
|
); |
|
|
|
}) |
|
|
|
|
|
|
|
For a much easier approach of binding Eigen types (although with some |
|
|
|
limitations), refer to the section on :ref:`eigen`. |
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/example7.cpp` contains a complete example that |
|
|
|
demonstrates using the buffer protocol with pybind11 in more detail. |
|
|
|
|
|
|
|
.. [#f1] http://docs.python.org/3/c-api/buffer.html |
|
|
|
.. [#f2] http://docs.python.org/3/c-api/buffer.html |
|
|
|
|
|
|
|
NumPy support |
|
|
|
============= |
|
|
|
@ -856,16 +1095,32 @@ type of Python object satisfying the buffer protocol). |
|
|
|
In many situations, we want to define a function which only accepts a NumPy |
|
|
|
array of a certain data type. This is possible via the ``py::array_t<T>`` |
|
|
|
template. For instance, the following function requires the argument to be a |
|
|
|
dense array of doubles in C-style ordering. |
|
|
|
NumPy array containing double precision values. |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
void f(py::array_t<double> array); |
|
|
|
|
|
|
|
When it is invoked with a different type (e.g. an integer), the binding code |
|
|
|
will attempt to cast the input into a NumPy array of the requested type. Note |
|
|
|
that this feature requires the :file:``pybind11/numpy.h`` header to be |
|
|
|
included. |
|
|
|
When it is invoked with a different type (e.g. an integer or a list of |
|
|
|
integers), the binding code will attempt to cast the input into a NumPy array |
|
|
|
of the requested type. Note that this feature requires the |
|
|
|
:file:``pybind11/numpy.h`` header to be included. |
|
|
|
|
|
|
|
Data in NumPy arrays is not guaranteed to packed in a dense manner; |
|
|
|
furthermore, entries can be separated by arbitrary column and row strides. |
|
|
|
Sometimes, it can be useful to require a function to only accept dense arrays |
|
|
|
using either the C (row-major) or Fortran (column-major) ordering. This can be |
|
|
|
accomplished via a second template argument with values ``py::array::c_style`` |
|
|
|
or ``py::array::f_style``. |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
void f(py::array_t<double, py::array::c_style | py::array::forcecast> array); |
|
|
|
|
|
|
|
The ``py::array::forcecast`` argument is the default value of the second |
|
|
|
template paramenter, and it ensures that non-conforming arguments are converted |
|
|
|
into an array satisfying the specified requirements instead of trying the next |
|
|
|
function overload. |
|
|
|
|
|
|
|
Vectorizing functions |
|
|
|
===================== |
|
|
|
@ -885,7 +1140,7 @@ After including the ``pybind11/numpy.h`` header, this is extremely simple: |
|
|
|
m.def("vectorized_func", py::vectorize(my_func)); |
|
|
|
|
|
|
|
Invoking the function like below causes 4 calls to be made to ``my_func`` with |
|
|
|
each of the the array elements. The significant advantage of this compared to |
|
|
|
each of the array elements. The significant advantage of this compared to |
|
|
|
solutions like ``numpy.vectorize()`` is that the loop over the elements runs |
|
|
|
entirely on the C++ side and can be crunched down into a tight, optimized loop |
|
|
|
by the compiler. The result is returned as a NumPy array of type |
|
|
|
@ -903,7 +1158,7 @@ arrays ``x`` and ``y`` are automatically converted into the right types (they |
|
|
|
are of type ``numpy.dtype.int64`` but need to be ``numpy.dtype.int32`` and |
|
|
|
``numpy.dtype.float32``, respectively) |
|
|
|
|
|
|
|
Sometimes we might want to explitly exclude an argument from the vectorization |
|
|
|
Sometimes we might want to explicitly exclude an argument from the vectorization |
|
|
|
because it makes little sense to wrap it in a NumPy array. For instance, |
|
|
|
suppose the function signature was |
|
|
|
|
|
|
|
@ -996,8 +1251,9 @@ For instance, the following statement iterates over a Python ``dict``: |
|
|
|
|
|
|
|
Available types include :class:`handle`, :class:`object`, :class:`bool_`, |
|
|
|
:class:`int_`, :class:`float_`, :class:`str`, :class:`bytes`, :class:`tuple`, |
|
|
|
:class:`list`, :class:`dict`, :class:`slice`, :class:`capsule`, |
|
|
|
:class:`function`, :class:`buffer`, :class:`array`, and :class:`array_t`. |
|
|
|
:class:`list`, :class:`dict`, :class:`slice`, :class:`none`, :class:`capsule`, |
|
|
|
:class:`iterable`, :class:`iterator`, :class:`function`, :class:`buffer`, |
|
|
|
:class:`array`, and :class:`array_t`. |
|
|
|
|
|
|
|
In this kind of mixed code, it is often necessary to convert arbitrary C++ |
|
|
|
types to Python, which can be done using :func:`cast`: |
|
|
|
@ -1015,11 +1271,31 @@ The reverse direction uses the following syntax: |
|
|
|
MyClass *cls = obj.cast<MyClass *>(); |
|
|
|
|
|
|
|
When conversion fails, both directions throw the exception :class:`cast_error`. |
|
|
|
It is also possible to call python functions via ``operator()``. |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
py::function f = <...>; |
|
|
|
py::object result_py = f(1234, "hello", some_instance); |
|
|
|
MyClass &result = result_py.cast<MyClass>(); |
|
|
|
|
|
|
|
The special ``f(*args)`` and ``f(*args, **kwargs)`` syntax is also supported to |
|
|
|
supply arbitrary argument and keyword lists, although these cannot be mixed |
|
|
|
with other parameters. |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
py::function f = <...>; |
|
|
|
py::tuple args = py::make_tuple(1234); |
|
|
|
py::dict kwargs; |
|
|
|
kwargs["y"] = py::cast(5678); |
|
|
|
py::object result = f(*args, **kwargs); |
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/example2.cpp` contains a complete example that |
|
|
|
demonstrates passing native Python types in more detail. |
|
|
|
demonstrates passing native Python types in more detail. The file |
|
|
|
:file:`example/example11.cpp` discusses usage of ``args`` and ``kwargs``. |
|
|
|
|
|
|
|
Default arguments revisited |
|
|
|
=========================== |
|
|
|
@ -1068,6 +1344,36 @@ like so: |
|
|
|
py::class_<MyClass>("MyClass") |
|
|
|
.def("myFunction", py::arg("arg") = (SomeType *) nullptr); |
|
|
|
|
|
|
|
Binding functions that accept arbitrary numbers of arguments and keywords arguments |
|
|
|
=================================================================================== |
|
|
|
|
|
|
|
Python provides a useful mechanism to define functions that accept arbitrary |
|
|
|
numbers of arguments and keyword arguments: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
def generic(*args, **kwargs): |
|
|
|
# .. do something with args and kwargs |
|
|
|
|
|
|
|
Such functions can also be created using pybind11: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
void generic(py::args args, py::kwargs kwargs) { |
|
|
|
/// .. do something with args |
|
|
|
if (kwargs) |
|
|
|
/// .. do something with kwargs |
|
|
|
} |
|
|
|
|
|
|
|
/// Binding code |
|
|
|
m.def("generic", &generic); |
|
|
|
|
|
|
|
(See ``example/example11.cpp``). The class ``py::args`` derives from |
|
|
|
``py::list`` and ``py::kwargs`` derives from ``py::dict`` Note that the |
|
|
|
``kwargs`` argument is invalid if no keyword arguments were actually provided. |
|
|
|
Please refer to the other examples for details on how to iterate over these, |
|
|
|
and on how to cast their entries into C++ objects. |
|
|
|
|
|
|
|
Partitioning code over multiple extension modules |
|
|
|
================================================= |
|
|
|
|
|
|
|
@ -1136,58 +1442,6 @@ accessed by multiple extension modules: |
|
|
|
}; |
|
|
|
|
|
|
|
|
|
|
|
Treating STL data structures as opaque objects |
|
|
|
============================================== |
|
|
|
|
|
|
|
pybind11 heavily relies on a template matching mechanism to convert parameters |
|
|
|
and return values that are constructed from STL data types such as vectors, |
|
|
|
linked lists, hash tables, etc. This even works in a recursive manner, for |
|
|
|
instance to deal with lists of hash maps of pairs of elementary and custom |
|
|
|
types, etc. |
|
|
|
|
|
|
|
A fundamental limitation of this approach is that the internal conversion |
|
|
|
between Python and C++ types involves a copy operation that prevents |
|
|
|
pass-by-reference semantics. What does this mean? |
|
|
|
|
|
|
|
Suppose we bind the following function |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
void append_1(std::vector<int> &v) { |
|
|
|
v.push_back(1); |
|
|
|
} |
|
|
|
|
|
|
|
and call it as follows from Python: |
|
|
|
|
|
|
|
.. code-block:: python |
|
|
|
|
|
|
|
>>> v = [5, 6] |
|
|
|
>>> append_1(v) |
|
|
|
>>> print(v) |
|
|
|
[5, 6] |
|
|
|
|
|
|
|
As you can see, when passing STL data structures by reference, modifications |
|
|
|
are not propagated back the Python side. To deal with situations where this |
|
|
|
desirable, pybind11 contains a simple template wrapper class named ``opaque<T>``. |
|
|
|
|
|
|
|
``opaque<T>`` disables the underlying template machinery for |
|
|
|
``T`` and can be used to treat STL types as opaque objects, whose contents are |
|
|
|
never inspected or extracted (thus, they can be passed by reference). |
|
|
|
The downside of this approach is that it the binding code becomes a bit more |
|
|
|
wordy. The above function can be bound using the following wrapper code: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
|
|
|
|
m.def("append_1", [](py::opaque<std::vector<int>> &v) { append_1(v); }); |
|
|
|
|
|
|
|
Opaque types must also have a dedicated ``class_`` declaration to define a |
|
|
|
set of admissible operations. |
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/example14.cpp` contains a complete example that |
|
|
|
demonstrates how to create opaque types using pybind11 in more detail. |
|
|
|
|
|
|
|
Pickling support |
|
|
|
================ |
|
|
|
|
|
|
|
@ -1210,7 +1464,7 @@ Suppose the class in question has the following signature: |
|
|
|
int m_extra = 0; |
|
|
|
}; |
|
|
|
|
|
|
|
The binding code including the requisite ``__setstate__`` and ``__getstate__`` methods [#f2]_ |
|
|
|
The binding code including the requisite ``__setstate__`` and ``__getstate__`` methods [#f3]_ |
|
|
|
looks as follows: |
|
|
|
|
|
|
|
.. code-block:: cpp |
|
|
|
@ -1247,27 +1501,29 @@ An instance can now be pickled as follows: |
|
|
|
|
|
|
|
p = Pickleable("test_value") |
|
|
|
p.setExtra(15) |
|
|
|
data = pickle.dumps(p, -1) |
|
|
|
data = pickle.dumps(p, 2) |
|
|
|
|
|
|
|
Note that only the cPickle module is supported on Python 2.7. It is also |
|
|
|
important to request usage of the highest protocol version using the ``-1`` |
|
|
|
argument to ``dumps``. Failure to follow these two steps will lead to important |
|
|
|
pybind11 memory allocation routines to be skipped during unpickling, which will |
|
|
|
likely cause memory corruption and/or segmentation faults. |
|
|
|
Note that only the cPickle module is supported on Python 2.7. The second |
|
|
|
argument to ``dumps`` is also crucial: it selects the pickle protocol version |
|
|
|
2, since the older version 1 is not supported. Newer versions are also fine—for |
|
|
|
instance, specify ``-1`` to always use the latest available version. Beware: |
|
|
|
failure to follow these instructions will cause important pybind11 memory |
|
|
|
allocation routines to be skipped during unpickling, which will likely lead to |
|
|
|
memory corruption and/or segmentation faults. |
|
|
|
|
|
|
|
.. seealso:: |
|
|
|
|
|
|
|
The file :file:`example/example15.cpp` contains a complete example that |
|
|
|
demonstrates how to pickle and unpickle types using pybind11 in more detail. |
|
|
|
|
|
|
|
.. [#f2] http://docs.python.org/3/library/pickle.html#pickling-class-instances |
|
|
|
.. [#f3] http://docs.python.org/3/library/pickle.html#pickling-class-instances |
|
|
|
|
|
|
|
Generating documentation using Sphinx |
|
|
|
===================================== |
|
|
|
|
|
|
|
Sphinx [#f3]_ has the ability to inspect the signatures and documentation |
|
|
|
Sphinx [#f4]_ has the ability to inspect the signatures and documentation |
|
|
|
strings in pybind11-based extension modules to automatically generate beautiful |
|
|
|
documentation in a variety formats. The pbtest repository [#f4]_ contains a |
|
|
|
documentation in a variety formats. The pbtest repository [#f5]_ contains a |
|
|
|
simple example repository which uses this approach. |
|
|
|
|
|
|
|
There are two potential gotchas when using this approach: first, make sure that |
|
|
|
@ -1294,6 +1550,5 @@ work, it is important that all lines are indented consistently, i.e.: |
|
|
|
---------- |
|
|
|
)mydelimiter"); |
|
|
|
|
|
|
|
.. [#f3] http://www.sphinx-doc.org |
|
|
|
.. [#f4] http://github.com/pybind/pbtest |
|
|
|
|
|
|
|
.. [#f4] http://www.sphinx-doc.org |
|
|
|
.. [#f5] http://github.com/pybind/pbtest |
Mavo
9 years ago
Matthias Volk
xxxxxxxxxx
